KEY SPECIFICATIONS

Loading Capacity

Driver: 12,000 lbs (6-ton)

Idler: 12,000 lbs (6-ton)

Footprint

Driver: 34-5/8" x 104-3/8" x 26-3/4";

Idler: 34" x 103-1/4" x 26-3/4"

Diameter Range

6” - 144”

Tractive Effort

3,500 lbs

Turning Torque

25,000 in-lbs

Turning Speed

5–50 in/min

Height Range

23-3/4" - 39" (top of wheel),

Adjustable in 3" increments

Power Requirements

115V, 1-ph or 208/230V, 1-ph

Weight

Driver: 1150 lbs

Idler: 735 lbs
