KEY SPECIFICATIONS
Loading Capacity |
80,000 lbs (40-ton) |
Footprint |
142-5/8” x 140” x 42-½” |
Spool Size Range |
OD: 60” - 192”, Roll Width: 120” Max |
Tractive Effort | 8,500 lbs (Single drive) |
Turning Torque | |
Turning Speed | 3 - 19 RPM (48 – 480 in/min) |
Height Range | 21-¼” - 24-¼” (top of roller), Fine screw height adjustment |
Power Requirements | 460V, 3-ph |
Weight | 7,160 lbs |
Brake Torque | Adjustable slip clutch - consult LJ Welding for specifications |
Controls | Variable Speed, Forward/Reverse AC Drive, optional foot or hand switches |
