KEY SPECIFICATIONS
Loading Capacity |
6,000 lbs (at 12" overhung load) |
Footprint |
67-⅞” x 52-⅞” x 53” |
Tilting Range |
-45° - 90° (vertical mounting plate datum) |
Tilting Torque |
125,000 in-lbs |
Tilting Speed |
0.1 - 1.0 RPM (135° in 25 seconds) |
Turning Torque |
60,000 in-lbs |
Turning Speed |
0.1 – 2.5 RPM (Other options available) |
Height Range |
32” - 52” (mounting plate height), Adjustable in 4” increments |
Mounting Plate Diameter |
42" (T-Slot Plate with 6 x 5/8" slots) |
Power Requirements |
480V, 7A, 3-ph, 60Hz |
Ground Capacity |
800 Amps |
Weight |
3,702 lbs |
