KEY SPECIFICATIONS
Loading Capacity |
20,000 lbs (Up to 6" Eccentricity) |
Footprint |
50” x 47-⅝” x 20-½” |
Turning Torque |
20,000 in-lbs |
Turning Speed |
0.1 - 3.5 RPM |
Mounting Plate Diameter |
42" (T-Slot Plate with 6 x 5/8" slots) |
Power Requirements |
120V, 15A, 1-ph, 60Hz |
Ground Capacity |
800 Amps |
Weight |
1,350 lbs |
