KEY SPECIFICATIONS

Loading Capacity

12,000 lbs (at 12" overhung load)

Footprint

89” x 63-⅞” x 74-⅛”

Tilting Range

-45° - 90° (vertical mounting plate datum)

Tilting Torque

250,000 in-lbs

Tilting Speed

0.1 - 1.0 RPM (135° in 25 seconds)

Turning Torque

125,000 in-lbs

Turning Speed

0.05–2.2 RPM (Other speed options available)

Height Range

48-1/8” - 80-1/8” (mounting plate height), Adjustable in 4” increments

Mounting Plate Diameter

48" (T-Slot Plate with 6 x 3/4" slots)

Power Requirements 480V, 13A, 3-ph, 60Hz
Ground Capacity 1,500 Amps
Weight 7,745 lbs
