KEY SPECIFICATIONS
Loading Capacity |
60,000 lbs (at 12” overhung load) |
Footprint |
133-½” x 96-½” x 105-3/16” |
Turning Torque |
800,000 in-lbs |
Turning Speed |
0.04 - 0.8 RPM |
Height Range |
72-1/4” - 144-1/4” (at mounting plate), Adjustable in 8” increments |
Mounting Plate Diameter |
62-1/2” |
Power Requirements |
480V, 31A, 3-ph, 60Hz |
Ground Capacity |
1500 Amps |
Weight |
20,462 lbs |
