|Load Capacity (at Boom End)||250 lb|
|Power Requirements||480V 3-ph*|
|Equipment Mass||4,400 lb|
*208 - 600V, 50 or 60 Hz input power options available
|Control platform (Joystick or fully integrated touchscreen options)|
|SAW or GMAW welding systems (Single, Twin, or Tandem wire)|
|Cold Wire TIG Systems|
|Powered cross slides (1 or 2 axis)|
|Weld Camera systems (SAW or Open Arc)|
|Seam Tracking (Vision/Laser or Tactile/Mechanical)|
|Travel Car (Powered or Manual)|
|Pre-heating system (Rolling Induction Heater)|
|Flux Recovery and delivery systems|
|Dual SAW or MIG/SAW set-ups|
LJ’s Column & Boom Manipulators are used in applications of automated welding, where precision and efficiency are necessary. They provide weld boom stiffness, welding head stability, operator controls, and ease of use as key driving factors
LJ's 4' x 5' GMAW Welding Column & Boom Manipulator Rentals have a loading capacity of 250 lb, boom stroke of 42" and column stroke of 58". This machine easily integrates with PEMA roller-beds and positioners. Operators also use it for welding longitudinal and circumferential seams. We also offer a wide selection of accessories and options available depending on the customer's request and need. As far as the welding source options are concerned, we offer submerged arc (SAW), MIG, or a solution to the customer’s specification. We also offer control upgrades including full integration to LJ welding positioners or turning rolls through HMI touchscreens and master PLC.
Generally, LJ's 4' x 5' GMAW Welding Column & Boom Manipulator Rentals are indispensable for applications that involve pipes and vessels, where they maximize productivity and efficiency. Our MNP-600 rental reduces rework/scrap and the final results aren't skilled dependable since the whole process is automated. They are ideal for hard automation welding solutions and they offer modular construction that ensures 360-degrees radial accessibility to welding heads, covering vast areas in the shop.
We, at LJ Welding, try to bring you the best products that satisfy your demands.
if you are looking for a Welding Manipulator with different specs, have a look at our:
LJ Welding's engineering department provides a progressive approach to solving the
unique problems that inevitably arise in our industry, resulting in efficient design,
fabrication, and timely delivery of custom equipment.
