KEY SPECIFICATIONS

Loading Capacity

20,000 lbs (10-ton)

Footprint

104-3/16” x 95-¾” x 29-¾”

Spool Size Range

OD: 24” - 96”,  Roll Width: 63” Max

Tractive Effort

880 lbs

Turning Torque

2,200 in-lbs

Turning Speed

2.5 - 47.5 RPM (30 - 750 in/min)

Height Range

19-1/8”” - 22-1/8” (top of roller), Fine height adjustment

Power Requirements

220 V, 1-ph

Weight

2,200 lbs

Brake Torque

Adjustable slip clutch - consult LJ Welding for specifications

Controls

Variable Speed, Forward/Reverse AC Drive, optional foot or hand switches
