5,400 lb Pipe Turning Positioner Rentals

KEY SPECIFICATIONS: 30P-200

Loading capacity 5,400 lb
(at Mounting Plate)
Footprint 72"x 42"x 77"
Turning Torque 40,000 in-lb
Height Adjustability 33"– 69" in 4"
increments
Power Requirements 480V, 3-ph*
Operation Speed 0.2–2.4 RPM
Ground Capacity 800 Amps

LARGE HEIGHT ADJUSTABILTY

Accommodation to a wide range of swing diameters.

PIPE TURNING POSITIONER RENTAL DESCRIPTION

Our 5,400 lb Pipe Turning Positioner Rental has a load capacity of 2.7 tons and turning torque of 40,000 in-lb. It is made from fabricated steel, provides height adjustability from 33" to 69" in 4" increments. The wide height range of the positioner aids in larger swing clearances. Apart from the height, the rotation speed of the positioner is adjustable also and can be adjusted between 0.2 to 2.4 RPM. We also offer optional accessories with this pipe turning positioner, like bidirectional cabled and wireless pendant with digital readout. On request, LJ can also offer variable speed style footswitches. For holding the workpieces, grippers, chucks and other speciality fixtures are available too.

PIPE TURNING POSITIONER RENTAL BENEFITS

LJ's 5,400 lb Pipe Turning Positioner Rental is ideal for workpieces that rotate on a horizontal axis and require support from one or two ends. It features extra heavy-duty worm gear, dynamic braking, and brake rotors. Together, these components ensure smoother control of the rotating movement along with enhanced stability and accessibility to significantly enhance welding quality. It also aids in improving the safety and productivity of the operators. This pipe welding positioner also ensures repeatable quality between batches and operators. Additionally, LJ’s pipe welding positioners for rent greatly enhance productivity when welding pipe, shafts, wheels, elbows and other fittings. Along with welding turntables, pipe welding positioners are particularly useful when rotating or positioning workpieces with large offset loads.
