1 Ton Multi-Directional - Beam Clamp Roller: MDR-200

MDR-200 1 ton multidirectional beam clamp pipe rollers

MDR-200 1 ton multidirectional pipe rigging equipment

MDR-200 1 ton multidirectional beam clamp rigging rollers

MDR-200 1 ton multidirectional beam rigging clamps

Decrease crane time by up to 40% to enhance workflow

Lower equipment and material damage for sustained quality

Increase job site safety and productivity with robust design

Safer, faster and easier installation and removal of pipes

Minimize material handling for efficiency in operations

Lower labor costs and streamline your processes

The MDR-200 is a 1-ton beam clamp roller that enhances pipe installation safety and efficiency.
It has a 2,000 lbs load capacity and allows for multidirectional movement of pipes.
This roller clamps securely to I-beams or support structures for stability in various industrial settings.
Ideal for refineries, power plants, and modular construction systems.
Reduces pinch points, tugging, and crane time, improving safety and productivity.
Can lower material handling costs by up to 40%.
High-grade urethane rollers provide grip, shock absorption, and pipe protection.
Supports pipe diameters from 2 to 24 inches, fitting various pipe sizes.
Adjustable beam clamp flange fits 4 to 12-inch widths and 1/4 to 1-3/4 inch thicknesses.
Handles make it easy to lift and install, ensuring simple setup.
Optional jacking systems and customization enhance functionality.
Other models like the MDR-700 (2 Ton) and MDRN-100 (1 Ton) are available for different needs.

Similar Equipment

At LJ Welding, we're dedicated to providing top-quality products that meet your needs.
If you're looking for a similar product with different specifications, be sure to check out our:

HZDD60-200
10 Ton Unidirectional - Beam Clamp Roller

MDRN-100
1 Ton Multi-Directional - Beam Clamp Roller

MDR-700
2 Ton Multi-Directional - Beam Clamp Roller

LJ Welding's engineering department provides a progressive approach to solving the
unique problems that inevitably arise in our industry, resulting in efficient design,
fabrication, and timely delivery of custom equipment.

Loading Capacity	2,000 lbs (1-ton)
Footprint	18” x 27-⅜” x 5-15/16”
Diameter Range	2" - 24"
Rolling Surface	Multi-Directional Roller
Beam Clamp Flange Size Range	4” - 12” Wide x 1/4” - 1-3/4” Thick
Weight	60 lbs

1 Ton Multi-Directional - Beam Clamp Roller: MDR-200

KEY SPECIFICATIONS

EQUIPMENT BENEFITS & DESCRIPTION

PHOTO GALLERY
